产品介绍
Specifications：ASTM B564 / ASME SB564
Size：1/2″ (15 NB) to 48″ (1200NB)
Payment way:T/T, L/C, can be negotitated
Description
|
Specifications |
ASTM B564 / ASME SB564 |
|
Dimensions |
ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc. |
|
Standard |
ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc. |
|
Size |
1/2″ (15 NB) to 48″ (1200NB) |
|
Class / Pressure |
150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc. |
|
Flange Face Type |
Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ) |
Equivalent Grades
|
STANDARD |
WERKSTOFF NR. |
UNS |
GOST |
AFNOR |
JIS |
BS |
EN |
OR |
|
Inconel 625 |
2.4856 |
N06625 |
ХН75МБТЮ |
NC22DNB4M |
NCF 625 |
NA 21 |
NiCr22Mo9Nb |
ЭИ602 |
Chemical Composition
|
Grade |
Ni |
Cr |
Fe |
C |
Mn |
Si |
Mo |
Co |
Al |
Ti |
Nb + Ta |
P |
S |
|
Inconel 625 |
58.0 min |
20.0 – 23.0 |
5.0 max |
0.10 max |
0.50 max |
0.50 max |
8.0 – 10.0 |
1.0 max |
0.40 max |
