C-276 Hastelloy Plate
Standard：ASTM B575 / ASME SB575
Dimensions：0.1 to 100 mm Thk
Thickness：10-2500mm
variety of shapes：Coils, Foils, Plates, Sheet, Strip
Description
C276 Hastelloy Plate is a highly resistant alloy that is widely used in various applications across industries. It is known for its superior resistance to corrosion, pitting, and crevice attack in severe environments. It finds its applications in various industries and is available in various forms, sizes, and thicknesses.
|
Specifications |
ASTM B575 / ASME SB575 |
| Thickness | 0.1 to 100 mm Thk |
| Width | 10-2500mm |
| variety of shapes | Coils, Foils, Plates, Sheet, Strip... |
Equivalent Grades
| STANDARD | WERKSTOFF NR. | UNS | JIS | GOST | EN | OR |
|---|---|---|---|---|---|---|
| Hastelloy C276 | 2.4819 | N10276 | NW 0276 | ХН65МВУ | NiMo16Cr15W | ЭП760 |
Chemical Composition
| Grade | C | Mn | Si | S | Co | Ni | Cr | Fe | Mo | P |
| C276 | 0.010 max | 1.00 max | 0.08 max | 0.03 max | 2.50 max | 50.99 min* | 14.50 – 16.50 | 4.00 – 7.00 | 15.00 – 17.00 | 0.04 max |
Mechanical Properties
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| C276 | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
Property Value
Density 8.89 g/cm³
Melting Point 1325 – 1370°C
Thermal Expansion Coefficient 11.2 µm/m°C
Electrical Resistivity 1.29 µΩ•m
Modulus of Elasticity 205 GPa
Nickel Alloy Applications
C276 Hastelloy Plate finds its applications in various industries due to its superior properties. Some of its applications include:
- Chemical processing – for equipment and processing units in corrosive environments
- Pollution control – scrubbers, ducting, and stack liners
- Pulp and paper – bleach plants, digester, and evaporators
- Waste treatment – incineration equipment, scrubbers, and ducting
- Food processing – chemical and processing applications
- Pharmaceutical – chemical and processing applications
