Spot black titanium round rod

Product Overview

Reviewed and maintained by the Engineering Team, Shaanxi Qianyi Tuoda Technology Co., Ltd.

Supply Status

Hot rolled/forged annealed black skin blank with hot-rolled oxide skin on the surface, without penetrating cracks or large slag inclusions.

[ Processing Technology ]

High temperature multi-directional forging of titanium ingots → hot rolling forming → overall stress relief annealing → straightening and shaping → ultrasonic testing → cutting to length and storing in stock.

[ Material Performance ]

TA2 pure titanium is resistant to corrosion from brine, dilute acid and alkali, and seawater, and is not easily corroded after long-term use; TC4 alloy has high strength, fatigue resistance, and high temperature resistance of 400 ℃. The overall density is low, and compared to steel parts, it reduces weight significantly. It is non-magnetic and does not interfere with precision equipment. After forging and rolling, it has excellent toughness, stable machining performance in turning, milling, drilling, forging, and welding, and sufficient rough machining allowance.

[ Process Structure ]

Adopting the repeated upsetting and drawing forging process to crush the coarse grains of the ingot and eliminate internal porosity and segregation defects; High temperature annealing releases forging stress, making subsequent mechanical processing less prone to vibration and deformation. The surface retains the original hot-rolled black skin, eliminating the polishing process and reducing raw material procurement costs; Each full-length non-destructive testing is conducted to eliminate internal hidden cracks and interlayers, meeting the processing standards for heavy-duty pressure bearing components.

[ Application Fields ]

1. Heavy chemical equipment

: corrosion-resistant mixing shaft, large flange, high-pressure valve body rough billet;

2. Marine engineering

: offshore anti-corrosion heavy-duty connectors, support components for large seawater equipment;

3. Vacuum heat treatment furnace

: high temperature resistant load-bearing pillars, large high-temperature tooling blanks;

4. Wet metallurgical equipment

: load-bearing shafts for immersion tanks, structural components for high temperature media containing salt;

5. General mechanical processing

: various corrosion-resistant non-standard shaft and fastener prefabricated blanks.
