Grade 9 Titanium Tubes from baoji
—— china baoji city Grade 9 Titanium Tubes
[ 信息发布：本站 | 时间：2024-02-19 | 浏览：196 ]
Grade 9 Titanium Tubes
Grade 9 Titanium Tube, also known as Gr 9 Titanium, is one of the most commonly used titanium alloys in the market. It is also referred to as 3al 2.5 V titanium, as it is composed of 3% aluminum, 2.5% vanadium, and the remaining element is pure titanium.
Product Material And Standard:
Material: Titanium alloy Gr.9 (3al 2.5 v titanium)
Standard: ASTM B338
Chemical Components
|
Material |
N |
C |
H |
Fe |
O |
Al |
V |
Pa |
Mo |
Ni |
Ti |
|
Grade 9 |
0.03 |
0.08 |
0.015 |
0.25 |
0.15 |
2.5-3.5 |
2.0-3.0 |
/ |
/ |
/ |
Balance |
Mechanical Property
| Material | Tensile strength(min) | Yeild strength(min) | Elongation(%) | ||
| Grade 9 |
ksi |
MPa |
ksi |
MPa |
|
|
125 |
860 |
105 |
725 |
10 |
|
Product Application:
- Seawater and Chemical processing: Grade 9 Titanium Tubes can be used to manufacture heat exchangers, coils, and condensers that are exposed to seawater and chemical environments. Its excellent corrosion resistance makes it a perfect fit in such applications.
- Aerospace and Marine industry: The high strength-to-weight ratio of Grade 9 Titanium Tubes makes it a preferred material in the aerospace and marine industry. It is used in the manufacturing of aircraft components, landing gears, and marine parts.
- Medical implants: Grade 9 Titanium Tubes are a biocompatible material that can be used in medical implants. It is commonly used in dental implants, artificial joints, screws, and plates.
- Sports equipment: The strength, flexibility, and lightweight features of Grade 9 Titanium Tubes make it a perfect material for sports equipment. It is used to manufacture bike frames, golf clubs, and other sports equipment.
